Raised bed floor tubs designed for 67-72 C-10 trucks with steel bed floors but adapt well in other applications. Dimensions are 38” long not including the 1" mounting flange around the perimeter. Handcrafted from TIG welded 18 gauge steel. Offered in raw finish only. Mounting flanges included for against bed side, final trim and fit against the bed side is responsibility of the customer. Includes 2 bed tubs and 2 mounting flanges.
Parts are built to order, Please refer to header at top of page for most up to date lead times!!
10” wheel - 7" tall 12.5” wide +1” flange
12” wheel - 7" tall 16” wide +1” flange
15” wheel - 8" tall 20.5” wide +1” flange
